The LKHA-16UP-M12G from Elco Automation is an IP67 Class-A IO-Link digital hub that concentrates 16 configurable PNP input or output channels onto one IO-Link connection.
- Eight M12 A-coded 5-pin signal sockets provide two independently usable digital channels per port
- Inputs accept PNP sensors, mechanical switches and dry contacts, with up to 200mA sensor supply per channel
- Outputs drive lamps, solenoid valves and similar loads at up to 500mA per channel and 2A in total
- Module power is supplied through the M12 A-coded Class-A IO-Link interface
- LED indication covers communication, power and channel status, with short-circuit, overload and low-voltage diagnostics
- Cast-zinc 145 × 55 × 27.5mm housing provides IP67 protection from -25°C to +70°C
