The Fi2-M12-LIU-Q12 from Elco Automation is a standard inductive proximity sensor in M12 threaded cylindrical housing, providing detection at up to 2mm.
- 2mm switching distance with flush mounting — the sensing face sits level with the mounting surface without losing range
- Analogue 0–10VDC / 0–20mA output on 15–30VDC supply
- 1000Hz switching frequency — high-speed counting and rapid presence detection
- M12 plug, 4-pin connector for fast field termination and replacement
- Nickel-plated brass M12 × 63.7mm housing — robust in metal-rich and mildly aggressive plant environments
- IP67 protection and -25°C to +70°C operating range; CE, RoHS, REACH certified
