The OS50-RVR5 from Elco Automation is a large-format photoelectric sensor in rectangular housing, providing detection at up to 10m.
- 10m operating range (Retro-reflective)
- Red light emitter — matched to industrial automation targets and surfaces
- Relay normally closed + normally open contact output on 24–250VAC/DC supply
- 50Hz switching frequency — standard response speed for general industrial control
- Hardwired PVC cable 2m — suitable for permanent or fixed mounting
- Plastic (PA66) 50 × 18 × 50mm housing — corrosion-immune in damp or mildly aggressive environments
- IP67 protection and -25°C to +55°C operating range; CE, RoHS, REACH certified
