| Light source | Halogen Lamp G6,35/GY6,35 |
| Light output | 20/25W |
| Peak Candela | 821 cd |
| Candela | 125 cd* (effective intensity) |
| Rotation speed | 180RPM (+/-30RPM) |
| Drive life | >5,000 hrs |
| Duty cycle | 100% |
| Lens colours | Amber, Blue, Clear, Green, Red & Yellow |
| Lens type | Plain |
| Mounting | Surface mount (right angle or pole mount accessories available) |
| Entries | 1 × 5-7mm push through grommet / 1 x M20 cable entry |
| Dimensions | ø100 x 150mm |
| Ingress protection | IP65 |
| Housing material | High impact UL94 V0 (f1) PC |
| Lens material | High impact UL94 V0 (f1) PC |
| Terminals | 1.5 mm² flying lead assembly |
| Operating temp | -25 to +50°C [-13° to +122°F] |
| Storage temp | -40 to +70°C [-40 to +158°F] |
| Relative humidity | 90% at 20°C [68°F] |
| Weight | 370g/0.81Ibs |
| Current Consumption |
| 12VDC | 1.72A |
| 24VDC | 0.91A |
| 115VAC 50/60Hz | 216mA |
| 230VAC 50/60Hz | 117mA |
