CRM-2H

CRM-2H | Asymmetric cycler

• Cycler with an independent adjustable  ON/OFF switch
• Used for regular room ventilation, cyclic dehumidification, light control, circulating pumps, illuminated advertising, etc.
• 2 time functions:
  • 1) Cycler beginning with pulse
  • 2) Cycler beginning with pause
• Function choice is done by an external jumper of terminals S-A1
• Time scale 0.1 s - 100 days devided into 10 time ranges: (0.1s - 1s / 1s - 10s / 0.1min - 1min / 1min - 10min / 0.1hrs - 1h / 1h - 10hrs / 0.1 day - 1 day /1 day - 10 days / 3 days - 30 days / 10 days - 100 days)
• Rough time setting via rotary switch
• Output indication: multifunction red LED

More information

• Number of functions: 2 (function is chosen by connecting S-A1)
• Supply terminals: A1 - A2
• Supply indication: green LED
• Operating position: any
• Mounting: DIN rail EN 60715
• Protection degree: IP40 from front panel / IP20 terminals
• Dimensions: 90 x 17.6 x 64mm
• Weight: 65g
