| Maximum output | High power level: 120dB(A) @ 1 m ±3dB / [111dB(A) @ 10ft/3m ±3dB] / Default power level: 117dB(A) @ 1 m ±3dB / [108dB(A) @ 10ft/3m ±3dB] |
|---|
| Nominal output | High power level: 118dB(A) @ 1m ±3dB / [109dB(A) @ 10ft/3m] ±3dB / Default power level: 114dB(A) @ 1m ±3dB / [105dB(A) @ 10ft/3m ±3dB] |
|---|
| No. of tones | 64 (UKOOA / PFEER compliant) |
|---|
| No. of stages | 4 |
|---|
| Volume control | Full range to 0dB(A) |
|---|
| Effective range | High power level: 214m/702ft @ 1KHz / Default power level: 153m/502ft @ 1KHz |
|---|
| Voltages DC | 11.5-54VDC |
|---|
| Voltages AC | 100-240VAC 50/60Hz |
|---|
| In rush | 815mA within 4.0ms @ 24VDC |
|---|
| Stage switching | Negative, positive, voltage free |
|---|
| Safety Integrity Level | SIL1 and SIL2 Route 2H IEC61508 (2010) |
|---|
| Ingress protection | IP66 Type 4/4X/13/3R |
|---|
| Enclosure | High impact UL94 V0 & 5VA FR ABS |
|---|
| Terminals | 0.5 – 2.5mm² (20-14 AWG) |
|---|
| Line monitoring | Diode polarized for use in supervised circuits |
|---|
| Operating | -40 to +66°C [-40° to +151°F] |
|---|
| Storage | -40 to +70°C [-40° to +158°F] |
|---|
| Relative humidity | 99% |
|---|
| Vibration test | 35Hz for a duration 4Hr (UL464) |
|---|
| Jarring test | 3ft/lb Energy (UL464) |
|---|
| Impact test | 3x 5lb (UL464) |
|---|
| MTBF DC | 93.92 years / 822,706 hours – MIL 217 |
|---|
| MTBF AC | 46.66 years / 408,508 hours – MIL 217 |
|---|
| Weight DC | 1.80kg / 3.96lbs |
|---|
| Weight AC | 2.10kg / 4.62lbs |
|---|
| Current Consumption |
|---|
| DC024 | 12VDC / 24VDC / 48VDC / 11.5-54VDC / 280mA / 224mA / 122mA / 376mA / 391mA / 223mA |
| AC230 | 115VAC 50/60Hz / 230VAC 50/60Hz / 100-240VAC / 100mA / 64mA / 173mA / 107mA |
