Name: B400RTH024B/R
Brand: E2S
SKU: B400RTH024B/R
Price: 523.79 AUD
Availability: InStock

B400RTH024B/R

B400RTH Rotating Beacon 35W 24VDC Red

B400RTH024B/R

Out of stock

B400RTH024B/R (red, 24VDC) - features:

$523.79

Excl. GST (Excl. GST)

Current Consumption
Light source	Halogen Lamp G6,35/GY6,35
Light output	35/40W
Peak Candela	1,204 cd
Candela	325 cd* (effective intensity)
Rotation speed	180RPM (+/-30RPM)
Drive life	>5,000 hrs
Duty cycle	100%
Lens colours	Amber, Blue, Clear, Green, Red & Yellow
Lens type	Plain
Mounting	Surface mount (right angle or pole mount accessories available)
Entries	1 × 5-7mm push through grommet / 2 x M20 cable entry
Dimensions	ø140 x 220mm
Ingress protection	IP65
Housing material	High impact UL94 V0 (f1) PC
Lens material	High impact UL94 V0 (f1) PC
Terminals	1.5 mm² flying lead assembly
Operating temp	-25 to +50°C [-13° to +122°F]
Storage temp	-40 to +70°C [-40° to +158°F]
Relative humidity	90% at 20°C [68°F]
Weight	578g/1.27Ibs
12VDC	3.0A
24VDC	1.54A
48VDC	840mA
115VAC 50/60Hz	338mA
230VAC 50/60Hz	186mA

B400RTH024B/R
