| Light source | High output L.E.D. |
|---|
| Light output | 18 x Cree© SMT White L.E.D. array |
|---|
| Function | High Power Steady / Blinking – 425ms ON 75ms OFF / 1.0Hz (60 fpm) – 200ms ON 800ms OFF / 1.33Hz (80fpm) – 150ms ON 600ms OFF / Double Flash / Triple Flash / 2.0Hz (120fpm) – 125ms ON 375ms OFF / Temporal Flash |
|---|
| Lens colours | Amber, Blue, Green, Red, Clear & Yellow |
|---|
| High Power Steady Candela | 356 cd – measured ref. to I.E.S. |
|---|
| 1Hz Flash Candela | 223 cd – measured ref. to I.E.S. |
|---|
| LED life | 60,000 hours |
|---|
| Terminals | Duplicated pluggable |
|---|
| Cable size | 0.5 to 2.5mm² (20-14 AWG) |
|---|
| Lens type | Prismatic/diffused |
|---|
| Mounting | Surface mount (Wall mount bracket available) |
|---|
| Entries | 1 × 5-7mm IP67 push through grommet / 2 × 20mm clearance cable entry |
|---|
| Dimensions | ø140 x 177mm |
|---|
| Ingress protection | IP65 |
|---|
| Housing material | High impact UL94 V0 (f1) PC |
|---|
| Operating temp | -40 to +70°C [-40° to +158°F] |
|---|
| Storage temp | -40 to +70°C [-40° to +158°F] |
|---|
| Relative humidity | 95% at 20°C [68°F] |
|---|
| Weight | 0.425Kg/0.934lbs |
|---|
| Current Consumption |
|---|
| Range | Version: / Current / Steady Mode: / Current / 1Hz Flash: / Max / Current: |
| 16-33VDC / 10-14VDC | 030 / 180mA (24VDC) / 88mA (24VDC) / 190mA (33VDC) |
| 48-260VAC / 48-260VDC | 230 / 90mA (115VAC) / 55mA (230VAC) / 156mA (48VDC) / 35mA (115VAC) / 18mA (230VAC) / 51mA (260VAC) |
