DRC-12V060W1RZ
Chrome II PSU 5A 60W 1ph 85-264VAC/12VDC
DRC-12V060W1RZ
In stock
The DRC-12V060W1RZ from Delta Electronics is a 12V 54W 4.5A DIN-rail-mounted switching power supply from the CHROME II Series, designed for industrial control cabinets and machine wiring.
- Regulated DC output delivering 12V at 4.5A for 54W total power
- Universal AC input accepts 85–264VAC at 47-63Hz for global deployment
- Output voltage adjustable 10.8–13.2VDC via front-panel trim
- Typical efficiency 87% typ. @ 115 Vac 88% typ. @ 230 Vac
- Rated for ambient operating temperature -30°C to +70°C (-40°C Cold Start)
- Ingress protection IP20
- Typical efficiency 87.0% at full load
$46.73
