DRL-48V240W1EN
LYTE II PSU 5A 240W 1ph 85-264VAC/48VDC
DRL-48V240W1EN
In stock
The DRL-48V240W1EN from Delta Electronics is a 48V 240W 5A DIN-rail-mounted switching power supply from the LYTE II Series, designed for industrial control cabinets and machine wiring.
- Regulated DC output delivering 48V at 5A for 240W total power
- Universal AC input accepts 90–264VAC at 47-63Hz for global deployment
- Output voltage adjustable 43.2–52.8VDC via front-panel trim
- Typical efficiency 90.5% typ. @ 230Vac
- Rated for ambient operating temperature -40°C to +70°C
- Typical efficiency 90.5% at full load
- Convection cooling — no fan required
$123.02
