NC8-M18-BN6L-Q12
M18 8mm 10-30VDC NPN NO+NC CAP PROXI
NC8-M18-BN6L-Q12
Out of stock
The NC8-M18-BN6L-Q12 from Elco Automation is a standard-size capacitive proximity sensor in M18 threaded cylindrical housing, providing detection at up to 8mm.
- 8mm switching distance with non-flush mounting — a clear zone around the sensing face is required to reach full range
- NPN normally closed contact and normally open contact output on 10–30VDC supply
- 50Hz switching frequency — standard response speed for general industrial control
- M12 plug, 4-pin connector for fast field termination and replacement
- Nickel-plated brass M18 × 76mm housing — robust in metal-rich and mildly aggressive plant environments
- IP67 protection and -25°C to +70°C operating range; CE, RoHS, REACH certified
$74.83
